X-Ray Solution Scattering Simulator

Proof of concept web interface for X-ray solution scattering simulation

Simulation Pipeline

Combine solute structural changes with solvent thermal response

Solute Difference

Compute intensity difference between excited and ground state molecular structures

\Delta I = I_{\text{exc}} - I_{\text{gnd}}

Solvent Response

Account for thermal expansion from pump laser energy deposition

\frac{\partial S}{\partial T} \cdot \Delta T

Combined Signal

Predict the total difference scattering as measured at the detector

\Delta S \approx \alpha \Delta S_{\text{sol}} + \Delta S_{\text{slv}}

Image Recreation

Simulate detector images based on detector information (geometry, masks, etc...) and combined scattering signal

...

Set up all parameters needed for accurate scattering predictions

Molecular Structures

Upload XYZ for ground and excited states. Supports arbitrary molecular geometries.

Solvent Library

Pre-loaded $\partial S/\partial T$ data for common solvents with temperature-dependent response curves.

Pump Parameters

Configure photon energy, excited state energy, and excitation fraction ( $\alpha$ ) for your optical pump.

Detector Geometry

Support for European XFEL detectors with configurable sample-detector distance.
